Binocular Research Microscope

Product Description

RSB-8    BINOCULAR RESEARCH PATHOLOGICAL MICROSCOPE        10490-00
     ( Model : RS-8)
    High quality Binocular Microscope for schools, colleges and research. Square sturdy base, streamlined design.

Binocular Head
     It is rotatable through 360° with inter pupillary distance 55 mm to 75mm and with a straight replaceable micro photographic tube.

Stage and Condenser
:     Rectangular 115 x 125 mm with co-axial mechanical stage. Sub stage movable by rack and pinion Abbe Condenser of 1.25 N.A. with iris diaphragm and filter.

Coarse and fine focusing
    Coarse focusing by rack and pinion for stage movement, built in locking device to avoid breakage to Slide. Fine focusing by graduated drum type helical screw graduated to 0.002 mm. Quadruple revolving nose piece with ball bearing movement. Supplied in wooden box having lock and key.

Illumination          Built in light in the base 6 volts, 20 W  with a step-down transformer.
Optics
    Eye piece                               15x Huygenian in pair, 10x WF in pair
    Objectives Achromatic        4x, 10x, 40 or 45x and 100x Oil Immersion spring loaded.

RSB-9    BINOCULAR RESEARCH MICROSCOPE  Co-axial focusing             17990-00
     (MODEL :  RS-88)
    SAME AS  MODEL RS-8 but  Coarse and fine Motion :  Co axial coarse and fine motion with sophisticated gear system. All movement on ball bearing.
